High-capacity 10 kW single-phase hybrid inverter with triple MPPT inputs, designed for large residential and light commercial solar-plus-storage systems in Australia.

• Supports up to 16 kW DC PV input and 10 kW AC output (peak overload 2× for 10s)

• Battery voltage 40–60 V with max charge/discharge current up to 220 A (12 kW model supports 250 A)

• Three MPPT trackers, each supporting two strings — ideal for optimizing multi-array configurations

• Parallelable up to 16 units, enabling scalable systems and three-phase setups

• Smart load/backup support: built-in ATS, AC coupling, diesel generator compatible, and energy scheduling for six charging/discharging periods

• Robust design: IP65, intelligent air cooling (<45 dB noise), color LCD touch display, RS485/CAN, WiFi/Bluetooth/LAN optional

• Efficiency: Max 97.6 %, Euro 96.5 %, MPPT >99 %

• Warranty: 10 years standard (5 years for certain installs)

• Compliance: AS/NZS 4777.2, IEC/EN safety & EMC standards, suitable for Australian grid injection
